TP-LINK (InSight S385PI) VIGI 8MP Outdoor IR Panoramic Bullet Network Camera, IP67, PoE, 180° Panorama, AI Detection/Classification, Red-Blue Warning Lights

+ click images to enlarge

Stock Code

WCA-INSIGHTTPS385PI

Manufacturer

TP-LINK

Manufacturer Code

INSIGHT S385PI

EAN Number

1210002612746

Printable Version

3 Available

You must be logged in to view pricing and place orders

Suitable for Outdoor

Yes

Wired/Wireless

Wired

Interface(s)

1 x RJ45 10/100M Self-Adaptive Ethernet Port, PoE
DC Power Port
Memory Card Slot (MicroSD Card up to 512GB)

Image Sensor

1/2.7” Progressive Scan CMOS

Resolution

Main Stream:
3840x2160,2560x1440,2304x1296,2048x1280,1920x1080,1280x720

Sub-Stream:
848x480,704x576, 640x480, 640x360,352x288, 320x240

Frame Rate

Main Stream:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Sub-Stream:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps

Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps

Video Compression

Main Stream:
H.265+/H.265/H.264+/H.264

Sub-Stream:
H.265/H.264

Lens

1.65mm Fixed Focal Lens
Lens Mount: M12
Aperture: F2.0

DORI Distance:
Detect: 144.36 ft (44 m)
Observe: 60.15 ft (18.33 m)
Recognize: 28.87 ft (8.8 m)
Identify: 14.44 ft (4.4 m)

Viewing Angle

Horizontal FOV: 180°
Vertical FOV: 86°
Diagonal FOV: 180°

Pan/Tilt/Rotation

Pan: 0° to 360°
Tilt: 0° to 90°
Rotation: 0° to 360°

Day/Night Mechanism

IR Cut Filter
Day/Night Switch: Unified/ Scheduled/ Auto

IR Working Distance

IR LED Quantity: 4
Range: 20m
Wavelength: 850nm
Illuminator On/Off Control: Auto/Scheduled/Always on/Always off

Minimum Illumination

0.005 Lux; 0 Lux with IR Light

Video Streaming

Main Stream
Sub-Stream

Image Settings

Mirror
Brightness
Contrast
Saturation
Sharpness
Exposure
WDR
White Balance
Prevent Overexposure to Infrared Light
HLC Adjustable by Client Software

Audio Features

Two-Way Audio
Audio Input: Built-in Microphone, Audio In Interface
Audio Output: Built-in Speaker, Audio Out Interface
Audio Compression: Yes
Audio Sampling Rate: 8 KHz
Environment Noise Filtering: Yes
Audio Bit Rate: 64 Kbps(G.711 alaw)

Alarm & Event Management

Smart Event Detection:
Intrusion, Line-Crossing, Region Entering, Region Exiting, Object Abandoned, Object Removal, Loitering, People, Vehicle, Abnormal Sound, Scene Change

Basic Event:
Motion Detection (Enhanced with Human & Vehicle Classification)
Video Tampering Detection
Exception (Illegal Login)
Alarm Input Device

Linkage Method:
Memory Card Video Recording
Upload to FTP Server
Alarm Output Device
Push Notifications
Send to Alarm Server
Active Defence-Sound & Light Alarm
Email Alarm

Network

Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP

ONVIF: Yes

API: Open Network Video Interface (Profile S/T/G)

Simultaneous Live View: 3 Main Streams & 3 Sub-Streams

Cloud: Yes

Wireless Features

Security

Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

Management

VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client

Power Supply

12V DC ± 5%, Max. 18W, 5.5 mm Coaxial Power Plug
PoE: 802.3at, Class 4, Max. 21W

Additional Features

180° Panorama View with Huge Vision
Red-Blue Warning Lights with Stronger Deterrence
IK10 Vandal Proof

Weight/Dimensions

1.01 kg
(LxWxH) 266 x 100 x 101 mm

Environment

IP67 Waterproof
Operating Temperature: -30–60 °C
Storage Temperature: -40–60 °C
Operating Humidity: 95% or Less (Non-Condensing)
Storage Humidity: 95% or Less (Non-Condensing)

Package Contents

VIGI Network Camera
Quick Start Guide
Waterproof Cable Attachments
Mounting Accessories

Package Weight

1.3800 kg

Warranty

5 Years

Full Box Quantity

Manufacturer Link

Click here for more details from the manufacturer
