Cables / Adapters > IPMI
Asus IPMI Expansion Card w/ Dedicated Ethernet Controller, VGA Port, PCIe 3.0 x1 & ASPEED AST2600A3 *OEM Packaging*
Stock Code
CON-AUIPMIV2
Manufacturer
ASUS
Manufacturer Code
90MC0AH0-MVUBY1
EAN Number
4711081525592
46 Available
You must be logged in to view pricing and place orders
Chipset
ASPEED AST2600A3
Interface
PCIe 3.0 x1
Internal RAM
System: 384MB
Video: 64MB
Video: 64MB
Internal ROM
64MB
Timers
32-bit Watchdog Timer
Features
Sensor monitoring & reporting when exceeding thresholds/failure
Fan and PSU monitoring and faillure alerting
IPMI 2.0 compliant
Cold boot
HTML5 Virtual Console (no Java)
SOL Support
SSH (SMASH 2.0) support
SNMP V3 Alerting
Update BIOS, BMC firmware via Web console or Linux tool
BIOS setting changing
Component Inventory Management
*Some of key features requires cable connection from this card to motherboard or PSU. For more details, please refer to user manual
Fan and PSU monitoring and faillure alerting
IPMI 2.0 compliant
Cold boot
HTML5 Virtual Console (no Java)
SOL Support
SSH (SMASH 2.0) support
SNMP V3 Alerting
Update BIOS, BMC firmware via Web console or Linux tool
BIOS setting changing
Component Inventory Management
*Some of key features requires cable connection from this card to motherboard or PSU. For more details, please refer to user manual
Graphics
1 x D-sub supports max. resolution 1920 x 1200 @ 60 Hz
External Connectors
1 x D-Sub
1 x LAN (RJ45) port
1 x LAN (RJ45) port
Internal Connectors
8 x fan headers
1 x 6-pin PSU connector
1 x BMC header
1 x SPI header
1 x PM_BUS header
1 x USB 2.0 connector
1 x VGA header
1 x Panel header(links to PWR/RST header)
3 x Tr sensor headers
1 x BMC switch jumper
1 x VGA switch jumper
1 x LOC switch jumper
1 x BMC Indicator LED
1 x 6-pin PSU connector
1 x BMC header
1 x SPI header
1 x PM_BUS header
1 x USB 2.0 connector
1 x VGA header
1 x Panel header(links to PWR/RST header)
3 x Tr sensor headers
1 x BMC switch jumper
1 x VGA switch jumper
1 x LOC switch jumper
1 x BMC Indicator LED
Operating System
Windows 10 - 64 bit, Linux OS including Cent OS, Redhat, and Ubuntu
Accessories
1 x BMC cable
1 x SPI cable
1 x Power On/Off cable
1 x Reset cable
1 x USB 2.0 cable
1 x IPMI TPM ADAPTER
1 x User manual
1 x SPI cable
1 x Power On/Off cable
1 x Reset cable
1 x USB 2.0 cable
1 x IPMI TPM ADAPTER
1 x User manual
Package Weight
0.3250 kg
Warranty
1 Year
Full Box Quantity
22
