TP-LINK (ES208GP) Omada 8-Port Gigabit Easy Managed Switch with 8-Port PoE+, Fanless, Metal Casing

+ click images to enlarge

Stock Code

SWI-8TPOMAGBEASYPOE

Manufacturer

TP-LINK

Manufacturer Code

ES208GP

EAN Number

1210002609715

Printable Version

Out of Stock: call for information

You must be logged in to view pricing and place orders

Rackmountable

Managed

Yes

Number of Ports

Max RJ45 Transfer Rate

10/100/1000 Mbps

Interface(s)

8 x 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+)

PoE Ports (RJ45)

Standard: 802.3af PoE and 802.3at PoE+ compliant
PoE Ports: 8 ports
PoE Budget: 64W available for all PoE+ ports, 30W max per port
Remote Camera Reboot
Up to 820ft (250m) PoE transmission distance

Switching Capacity

16 Gbps

Power Supply

DC Power Adapter (Output: 53.5V DC / 1.31A)

Dimensions

158 x 100.7 x 25.4 mm

Transfer Method

Store-And-Forward

Mac Address Table

Packet Forwarding Rate

11.904 Mpps

Jumbo Frame

15 KB

Additional Features

Fanless
Durable metal casing
Desktop/wall mounting design
Physical security lock

Quality of Service

802.1p DSCP Priority
8 Priority Queues
Priority Schedule Mode
Queue Weight Config
Bandwidth Control
Storm Control

Layer Features

L2 Features:
Link Aggregation
Loopback Detection
Flow Control
Mirroring
Port Statistics
802.1ab LLDP

L2 Multicast:
IGMP Snooping

VLAN

MTU VLAN
Port-Based VLAN
802.1Q Tag VLAN

Management

Omada App:
Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Centralized Management:
Omada Cloud-Based Controller
Omada Hardware Controller
Omada Software Controller

Cloud Access:
Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Zero-Touch Provisioning:
Requires the use of Omada Cloud-Based Controller

Management Features:
Web-based GUI
DHCP Client
Cable Diagnostics

Environment

Operating Temperature: 0°C ~40°C
Storage Temperature: -40°C ~70°C
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Package Contents

ES208GP
Power Adapter
Power Cord
Installation Guide
Rubber Feet

Package Type

Retail

Package Weight

0.9900 kg

Warranty

Limited Lifetime

Full Box Quantity

Manufacturer Link

Click here for more details from the manufacturer
