TP-LINK (EAP787) BE12000 Tri-Band Ceiling Mount Wi-Fi 7 Access Point, PoE++, 10GB Port, Omada Mesh, MLO, Multi-RUs

+ click images to enlarge

Stock Code

AP-12000TPEAP787

Manufacturer

TP-LINK

Manufacturer Code

EAP787

EAN Number

1210002600576

Printable Version

Out of Stock: call for information

You must be logged in to view pricing and place orders

Primary Function

Access Point

Bands

Tri Band

Wi-Fi Rating

BE12000

Max Single Band Wi-Fi Rate

5765 Mbps

Max Wired Transfer Rate

10 Gbps

Interface(s)

1 x 10G/2.5G Ethernet Port

Wireless Standards

IEEE 802.11 a/b/g/n/ac/ax/be

Antenna(s)

2.4 GHz: 2x 4.0 dBi
5 GHz: 4x 5.0 dBi
6 GHz: 2x 5.0 dBi

Button(s)

Reset

Power Supply

802.3bt/at PoE or 12V/2.5A DC
NOTE: Power Adapter is NOT included.

Power Consumption

26.3 W (For PoE);
22.4 W (For DC)

Dimensions

220 x 220 x 38.8 mm

Frequency

2.4GHz: Up to 688 Mbps
5GHz: Up to 5765 Mbps
6GHz: Up to 5765 Mbps

EIRP

6-20 dBm (2.4 GHz, EIRP)
9-23 dBm (5 GHz, U-NII-1 & U-NII-2A, EIRP)
9-30 dBm (5 GHz, U-NII-2C, EIRP)
6-23 dBm (6 GHz, EIRP)

Wireless Functions

320 MHz Bandwidth
MLO
4K-QAM
Multi-RUs
Seamless Roaming(802.11k/v/r)
MU-MIMO
Mesh
BSS Coloring
OFDMA
Load Balance
Band Steering
Beamforming
Airtime Fairness
Multiple SSIDS:24(8 on each band)
Wireless Schedule
Reboot Schedule
Rate Limit
Static IP/Dynamic IP
RADIUS Accounting
MAC Authentication

Security

Captive Portal Authentication
Access Control
Mac Filter
Wireless Isolation Between Clients
VLAN
Rogue AP Detection
WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Wireless Range

2050 ft2

Quality of Service

QoS(WMM)

Management

Omada App
Centralized Management
Cloud Access
Email Alerts
LED ON/OFF Control
Management MAC Access Control
SNMP v1, v2c, v3
System Logging Local/Remote Syslog
Web-based Management

Additional Features

Bluetooth: 1 x 5 dBi (peak gain), Internal antenna module
Mounting: Ceiling / Wall/ Junction Box Mounting (Kits Included)
Concurrent Clients: 510+

Environment

Operating Temperature: 0–40 °C (32–104 °F)
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing

Package Contents

EAP787
Installation Guide
Ceiling/Wall/Junction Box Mounting Kit
Note: Power Adapter is NOT included.

Package Type

Retail

Package Weight

1.4900 kg

Warranty

Limited Lifetime

Full Box Quantity

Manufacturer Link

Click here for more details from the manufacturer
